Front hub motor 500w for electric bike

Motor EEB DD/F/ 48V500W

  • Brand: EVEL
  • Product Code: EEB/DD(F)48v500w
50 or more : 54.00$

We can make windings, logo and connectors according to customer requirements. The minimum quantity with the required parameters is 20pcs.

Front direct drive (gearless) brushless hub-motor EEB DD/F/ 48V500W  is a perfect balanced solution for the electric powered bikes or conversion kit with 40-45kph speed.

Disc brake mount ISO 6 x 44mm
Freewheel mount 35mm thread.

Rear dropout size 100mm  X 10мм.

Recommended rim 20, 24, 26, 27,5, 28, 29 inch.

Windings - 7T

Magnets - 46 pcs 27mm height.

Phase cables AWG12 - 2,5mm2.

Holes for the spokes - 36pcs 2,3-2,6mm (12-13G)

Axle 14х10mm

Recommended controller - 48V 30A

Rated power 500W, Max continuous power 1000W

Unloaded RPM (48v) - 410rpm

Motor type - BLDC 205/30 direct drive hub-motor

Weight 5,8kg

Can be supplied with MT60 or waterproof juliette connector.
